Product Specifications
Type
AC Squirrel Cage Induction Motor
Frame
63 to 132M
Rated Power
0.18kW to 7.5kW (0.25hp to 10hp)
Rated Speed
3000, 1500, 1000
Frequency Variation
50Hz
Voltage Variation
415V or 230V
Mounting
Foot type or Flange type B3 / B5
Enclosure
TEFC (Total Enclosed Fan Cooled)
Cooling Method
IC 41 (Shaft Mounted Fan)
Degree of Protection
IP44 / IP55
Duty
S1 / Continuous
Ambient Temperature
50°C
Insulation Class
Class F
Direction of Rotation
Clockwise & Anticlockwise (as seen from Drive End Side)
Altitude
Lower than 1000 meters above sea level
Applications
Download Our Catalogue
Explore our complete product range. Download our latest catalogue to see all available models, specifications, and details.
Product Information
Product Name
Induction Motor
Category
Bearing
SKF Brand
Stamping
M43 High Grade of Silicon Stamping
Casting
Electrolytic Grade Alluminium Casting
Cable
PTFE RR Kabel Brand
Winding
OWN Cure Varnish Backing
